Parameter Settings – F 20 (Continued)
Inch Linear Encoders (BT or JB Linear Encoders)
NOTE: It is presumed that steps 1 through 3 have been performed first and Inch linear
encoder type was selected. If you selected Metric linear encoder type, go to
the Metric Linear Encoders section.
The DRO displays the following in the selected axis display(s) (for example, the X-axis):
X i.000000
ABS
INCH
The axis designation is blinking indicating that a value can be entered. The default
value for the encoder resolution is .0001 inch (ten thousands of an inch). This value
must be exact for the specific encoder used for feedback. Refer to the previous table for
the encoder resolution settings for common ANILAM encoders.
