Axis Reset Only – F 16
F 16 is useful for quick positioning. Press the axis key once to zero the display in either
ABS or INCR Mode.
Example 1: Set X-axis as Axis Reset Only.
1. Press
to select the feature.
2. Press the desired axis key to select the axis.
3. Press
to set the feature and
return to the operation.
Example 2:
Set X- and Y-axes as Axis Reset Only.
1. Press
to select the feature.
2. Press the desired axis key to select the axis.
3. Press
to set the feature and
return to the operation.
The DRO turns ON the RST symbol in the axis display.
Axis Reset Only
Indicato
r
X .00000
RST
NOTE: Perform the same procedure to turn OFF Axis Reset.
