Anilam Wizard 211 - Evertrack TM Mode - F 02

24
EverTrack
TM
Mode – F 02 (Continued)
7. Press
This will be the absolute part zero for the selected axis.
NOTE: You can also preset a dimension as long as the DRO is in Absolute Mode. The
zero position corresponding to the stored preset dimension will be stored and
can be recalled using EverTrack
TM
Mode.
CAUTION: If you require a temporary datum while in EverTrack
TM
Mode, we
recommend you exit the feature before you set the temporary datum.
To exit EverTrack
TM
Mode:
8. Press
9. Press
The RI turns off and the DRO stores the absolute part zero position. Now you can
perform an absolute reset (Axis key + Set key) on an axis or an absolute reset
(Absolute Zero Set – F 01
).
Setting a Part Zero – All Axes
To set up a part zero position for all axes:
1. Press to select the feature.
2. Press
The axis displays reset to zero and the RIs begin to blink for each axis.
CAUTION: During the following step, do not change the machine axis travel
direction. This will cause an error.
3. Move each machine axis approximately 1 inch (25.4 mm) in one direction until the
RIs stop blinking and the display starts to count.
