08
Figure: Installation space for wall-mounted modules.
＞500 mm
Length varies based upon your home.
＞500 mm
≥ 300 mm ≥ 300 mm
300-600 mm 300-600 mm 300-600 mm
≥ 500
mm
Side View Front View
Maximum Length of Signal Cable
Data Exchange Between Devices Maximum Length of Signal Cable
Power Module to Power Module 30 m
4.4 Prepare Tools and Supplies
The following tools and supplies are not included in the package. Ensure that you have them ready before proceeding with the
installation and electrical connections.
Required Tools
Use appropriate personal protective equipment (PPE) and follow safe electrical work practices.
Personal Protective Equipment
Protective Gloves Insulated Gloves
Dust Mask Safety Goggles
Protective Footwear Safety Hat
