Anker SOLIX X1 - About this Guide; Intended Audience; Check before Installation

01
1. About This Guide
1.1 Purpose
This guide describes Anker SOLIX X1 in terms of unboxing, product overview, installation, electrical connections,
commissioning, screen and light guide, maintenance, customer service, system information, and safety guidelines.
Anker SOLIX X1 includes one or more power modules and battery modules.
·
A power module can support up to six battery modules.
Model Product Name Shortened Form
X1-P6K-S Anker SOLIX X1 Power Module Power module
X1-B5-H0 Anker SOLIX X1 Battery Module Battery module
1.2 Intended Audience
This guide is intended for:
·
Sales engineers
·
System engineers
·
Technical support engineers
2. Unboxing
2.1 Check Before Installation
Check the Outer Packing
Before unpacking the equipment, check the outer packing for damage, such as holes and cracks, and check the equipment
model. If any damage is found or the model is not what you requested, do not unpack the equipment and contact the supplier
as soon as possible.
Check Deliverables
After unpacking the equipment, check that the deliverables are intact and complete, and free from any obvious damage. The
deliverables may vary due to batch variations. Please refer to the packing list for the actual packaged items. If any item is
missing or damaged, contact the supplier.
2.2 In the Power Module Box
No. Item Specifications Amount
1 Power Module X1-P6K-S 1
2 WLAN Dongle DG-WF-H 1
3 Heat Shrink Tubing
Black
Caliber: 8 mm
Length: 25 mm
1
4 Module Interlocker 38×17×2.5 mm 2
5 Wall Mount Bracket 575×65×26 mm 1
6 Floor Mounting Base
For Floor Mounting
670×150×75 mm
1
7 Left Side Cover 133×24.5×335 mm 1
8 Right Side Cover 133×24.5×335 mm 1
9 Male Dust Cap
Black
10.6×7.6×3.8 mm
1
10 Female Dust Cap
Black
19.3×25×8.3 mm
1
11 3-Pin Terminal Block Connector 7.5×11.75×19.2 mm 2
12 2-Pin Terminal Block Connector 5×11.75×19.2 mm 1
13 AC Connector
O-White
3 Pins
76.7 mm
1
