02
14 AC Connector
Black
3 Pins
76.7 mm
1
15 RJ45 Connector with 2×120Ω Resistors
8 Pins
Black
1
16 RJ45 Connector 8 Pins 3
17 Insulated Tube Terminal (COM) For Signal Cables (0.2-0.35 mm²) 12
18 Insulated Tube Terminal (Meter) For Meter Signal Cables ( 0.2-0.5 mm²) 2
19 Insulated Tube Terminal (AC)
Length: 19.5 mm
For AC Cables (6 mm²)
7
20 Ring Terminal RNB5.5-5 1
21 Self-Tapping Screw with Plastic Anchor M6×50 mm 2
22 Wedge Shim 118 × 40 × 7 mm 1
23 Bolt M5×14 mm 7
24 Flat Washer M12 3
25 Packing List / 2
26 Quick Installation Guide / 1
27 Inspection Report / 1
28 Positioning Card / 1
29 Safety Instructions / 1
2.3 In the Battery Module Box
No. Item Specifications Amount
1 Battery Module X1-B5-H0 1
2 Rubber Plug For Side Cover 2
3 RJ45 Signal Cable Black 1
4 Module Interlocker 38 × 17 × 2.5 mm 2
5 Side Cover
Black
360 × 117.4 × 21.8 mm
2
6 Negative DC Power Cable
Length: 130 mm
8 mm²
Black
1
7 Positive DC Power Cable
Length: 130 mm
8 mm²
Red
1
8 GND Cable
6 mm²
Yellow/Green
1
9 Wall Mount Bracket 575 × 65 × 26 mm 1
10 Bolt M5×14 mm 7
11 Self-Tapping Screw with Plastic Anchor M6×50 mm 2
12 Packing List / 1
13 Inspection Report / 1
14 Safety Instructions / 1
2.4 Optional Accessories and Service Parts
The following accessories must be ordered separately. Some service parts, such as the side covers and wall mount brackets,
can be replaced during field installation in accordance with the instructions provided in this guide.
