Anker SOLIX X1 - Page 6

03
Wall-Mount Kit
No. Item Specifications Amount
1 Bracket Holder 155.5×65×240 mm 2
2 Baseplate 670×150×51.5 mm 1
3 Left Baseplate Bae 143.5×24×50 mm 1
4 Right Baseplate Bae 143.5×24×50 mm 1
5 Screw M8×70 mm 4
6 Screw M4×10 mm 8
Top Cover Kit
No. Item Specifications Amount
1 Battery Module Top Cover 670×150×51.5 mm 1
2 Top Cover Bae 145.6×50.5×10 mm 2
3 Module Interlocker 38×17×2.5 mm 2
4 Screw M4×10 mm 8
5 Screw M5×14 mm 6
2nd Column Battery Module Accessory Kit
No. Item Specifications Amount
1 RJ45 Connector 8 Pins 2
2 Positive DC Power Connector For 8 mm² Cable 2
3 Negative DC Power Connector For 8 mm² Cable 2
4 Ring Terminal RNB5.5-5 2
5 Heat Shrink Tubing
Black
Caliber: 8 mm
Length: 25 mm
2
6 Screw M5×14 mm 2
3. At a Glance
3.1 Anker SOLIX X1
Figure: Appearance of the Anker SOLIX X1.
1
3
2
5
4
