3-6 Directivity and Test Port Match Verification Chapter 3 — Performance Verification
3-8 PN: 10410-00730 Rev. D MN469xC Series Multiport Test Set MM
23. Select Save Table to File
a. Enter the file name and click OK to save the Table.
24. Select Back | Sweep Type | Segmented Sweep (Freq-based)
25. Ensure that Tr1 is highlighted. If not, move the mouse pointer over Tr1 and click to select.
26. Select Display | Trace Format | Log Mag
27. Change Display Trace Format of Tr2, Tr3, Tr4 to Log Mag.
Table 3-2. VectorStar VNA Segmented Sweep Setup for VNA System with MN4694C Test Set
F1 F2 # of Pts IFBW P1 Src Pwr P2 Src Pwr
70 kHz 200 kHz 11 10 Hz 5 dBm 5 dBm
300 kHz 1 MHz 21 10 Hz 5 dBm 5 dBm
2 MHz 9 MHz 21 10 Hz 5 dBm 5 dBm
10 MHz 998 MHz 51 10 Hz 5 dBm 5 dBm
1000 MHz 2499 MHz 51 1 kHz 5 dBm 5 dBm
2500 MHz 5000 MHz 51 1 kHz 5 dBm 5 dBm
5001 MHz 20000 MHz 401 1 kHz 5 dBm 5 dBm
20001 MHz 38000 MHz 601 1 kHz 5 dBm 5 dBm
38001 MHz 40000 MHz 51 1 kHz 5 dBm 5 dBm
Table 3-3. VectorStar VNA Segmented Sweep Setup for VNA System with MN4697C Test Set
F1 F2 # of Pts IFBW P1 Src Pwr P2 Src Pwr
70 kHz 200 kHz 11 10 Hz 8 dBm 8 dBm
300 kHz 1 MHz 21 10 Hz 
8 dBm 8 dBm
2 MHz 9 MHz 21 10 Hz 8 dBm 8 dBm
10 MHz 998 MHz 51 10 Hz 8 dBm 8 dBm
1000 MHz 2499 MHz 51 1 kHz 8 dBm 8 dBm
2500 MHz 5000 MHz 51 1 kHz 8 dBm 8 dBm
5001 MHz 20000 MHz 401 1 kHz 8 dBm 8 dBm
20001 MHz 38000 MHz 601 1 kHz 8 dBm 8 dBm
38001 MHz 40000 MHz 51 1 kHz 8 dBm 8 dBm
40001 MHz 50000 MHz 201 1 kHz 8 dBm 8 dBm
50001 MHz 65000 MHz 151 1 kHz 8 dBm 8 dBm
65001 MHz 67000 MHz 51 1 kHz 8 dBm 8 dBm
67001 MHz 70000 MHz 51 1 kHz 8 dBm 8 dBm
