Antunes VCT-2 - Page 19

19
®
P/N 1011550 Rev. D 03/21
Item
No.
Part # Description Qty.
77 4000202 Fan, Axial 230V 1
78 4010187 Transformer, 240 Vac/12Vac 1
79 4010245 Rocker Switch 1
80 4030332 Thermostat, Hi-Limit 1
81 4050214
Thermocouple Type “K” (Open
End)
1
82 4051063
Relay, Random Phase, Solid
State
1
83 4060234 Wire Strap - 3/7” 1
84 4060303 Bus Bar Contact 3-Pole 1
86 4070202 Assy-Pbc, Display 1
88 7002037
Black Wavy Silicon Hook Belt
(2 pack)
1
93 3080102*
Washer, Int. Tooth #09 Steel;
Zinc Plated
4
96 3080181*
Screw, Mach. #8-32 X 3/8” Lg
Phthd, 18-8 S/S Brt
4
97 7000779 Rail, Slide Kit (Large) 1
98 0400436 Sheet, Platen Cover 1
100 7001115 Idler Sprocket Replacement Kit 1
101 4070383 Board, Line Filter 1
102 0022789 Air Filter Weldment 1
103 0013260 Drive Chain Tensionser 1
104 0600155 Compression Setting Spring 1
99 7001084 Cleaning Tool Kit - VCT-2 1
100 7001115 Idler Sprocket Replacement Kit 1
101 7001372 Relay Board Kit 1
102 7001602 Ba󰀪e Kit 1
103 7001529 Drive Chain Tensionser 1
104 0600155 Compression Setting Spring 1
105 1070014
Label - QR Code, VCT-2
(9210922 ONLY)
106 3100157 Washer, Flat #10 4
107 3100224
Set Screw, Knurl Grip Cup
Point, 10-32 UNF-2A X 1/4”
1
108 4060355 Terminal Block 3 Pole
1
109 3060101 Nut, Hex #6-32 St. Stl
2
110 0701106 VCT-2 Int. Wire Set 1
111 5206004
Tape, PTFE 10 Mil X 1WD X 18
YDS - 500 Deg. F
A/R
112 0600179 Extension Spring 4
* Item available in packages of ten (10).
Replacement Parts (Continued)
