AnyCubic VYPER - Electrical Wiring Connections

www.anycubic.com
18
Installation
5. Wiring: connect all these wires to their corresponding ports by the
label respectively.
2. Screen wires
3. Extruder/X motor wires
7. Left Z motor
6. Left Z limit switch
4. Right Z limit switch
5. Right Z motor
2
3
4,
5
6,
7
1
1. Print head wires
