3. Release the front section from the window frame.
4. Release the front bow from the window frame on both side of the cockpit, but
let the bow stay attached to the canopy roof section.
5. Fold the canopy roof and front section around the mid-canopy bow, and lower
it into the garage.
6. Finally, place the rolled side sections in the garage, on top of the rest of the
canopy and close the garage lid.
7. To mount the canopy again, reverse the above steps.
4.11 ANYTEC HIGH PERFORMANCE SEAT SUSPENSION
The Anytec high-performance suspension seats absorb shocks and vibrations coming
from rides in rough waters. They are specially developed and manufactured by Anytec
and include the top-of-the-line suspension units by Ohlin’s. The seat height, as well as the
suspension rate, can be adjusted manually.
1. The seat height can be
adjustable by moving these
fasteners back or forward.
To adjust the spring preload, compression damping, rebound damping and to adjust length
of the shock absorber please refer to the Ohlin’s owner manual. It is provided with the
Anytec document bag.
4.12 WATERSPORT TOW ROPE ATTACHMENT
Your boat comes equipped with an attachment point for watersport tow ropes,
integrated to the targa.
The attachment point is only to be used for water skiing wakeboarding or tubing. It is
not designed for towing boats, parachutes and kites or similar. Attach the tow rope
around the 40 mm thick pipe, and inside the arc area. The purpose of the arc is only to
prevent the line to shift sideways, NOT to hold the rope.
