Remote control of switches:
The battery main switches can also be operated remotely by remote switches installed at
the helm. As standard 2 such switches are provided at the helm, whereof 1 or 2 are used
depending on how many batteries that are installed. See the figure in chapter 5.4. If the
boat has an optional bow thruster, there will be a 3rd remote control switch for the
thruster battery (not shown in the figure).
If the emergency start cross switch is used, turn it off immediately after the engine has
started. Failure to do so may damage the batteries.
5.4 FUSES AND BREAKERS
Your boat is equipped with fuses protecting the DC electrical system. The fuses can be
reset if they trip, by pushing the fuse button. They are individually marked.
1. Fuse & main switch panel 4. Cross switch
2. Circuit breakers 5. Service battery main switch
3. Start battery main switch
