2. STANDARD ACCESSORIES
3. OPTIONAL ACCESSORIES
4. INSTALLATION
8 ohm speaker
PC cable
Choose a idea location to install the radio.
1. Mark the location for screws by intall racket.
2. Fix the bracket by screws.
3. Fix radio base into install bracket and lock by adjusting knobs.
Radio
Screws
Microphone
Pads
Adjusting screws
Microphone Hanger
Install bracket
non-slip mat
Fuse(5A 250V)
MIC
P1
FUNC
P4
P5
P6
P2
P3
