AnyTone AT-D868UV Programming Guide

AT-D868UV CodePlug Programming Guide
V-1.18
Page 25 of 25 © 2017 Trygve Svärd KD0PNQ
RADIO LCD DISPLAY
On the top row of the LED display the following indications can appear:
 Reception bars showing signal strength
 Within a square “L/M/H/T” transmit power levels showing from Low to Turbo
 Headset = Digital Monitor is turned on
 GPS symbol gray = no GPS signal received, red = GPS signal received
 “A” indicates a set-up for Auto Power Off
 DCS or CTC for Analog reception tone signaling
 R next to a digital channel = connected to repeater with different RX and TX
frequency.
Note: Any updates or corrections to this Programming Guide should be forwarded to
AnyTone at zsxqlx6833@qxdz.cn
