Parts Description
2-4
2.2. Back Panel
There are four components available to be installed on the back panel of H800: (1) Power
Supply, (2) I/O Ports, (3) Expansion Slots, and (4) Housing Fans.
2.2.1 Power Supply
The H800 provides 2 solutions:
1. Standard ATX 12V 350W/400W power supply : you have to assemble this standard ATX
12V power together with the power bracket before installed to chassis.
b
Power Bracket
Standard ATX 12V
350/400W
2. Redundant 337W power supply (with or without 2
nd
power)
337W Redundant
Power Cage
337W main power
2
n
To Next Page
