3.4. Installing FDD and 5.25” CD-ROM into Chassis
 Slide the FDD with slide rails and cables into the drive bay.
 Slide the 5.25” CD-ROM with slide rails into the drive bay.
 You may fasten the 5.25” CD-ROM with four screws if the slide rails are not
available.
e
The 1st location don’t support screw
way, it just can support rail way only.
d
H800 Server Chassis
