3.5. Installing HDD Cage into Chassis
Note: The hard disk is a sensitive mass storage device. Any accidentally impact on
the hard disk might cause serious damage, so please handle it with care.
Insert the 8cm fan into the HDD cage for a better heat-dissipation if necessary and
fasten it with four screws.
Secure each slide rails on the left and right side of HDD cage with four screws.
Fix the HDD into HDD cage by screw.
Slide the HDD cage into the drive bay.
