Parts Description
2-13
When testing the power supply must operate within the listed requirements.
OTHER REQUIREMENTS
COOLING
With the fan voltage set to around 12 volts, the fan will deliver greater than 38 CFM
with the power supply in open air.
INPUT CONNECTIONS
Refer to Mechanical Specifications for placement.
The AC mains input are through a three-circuit IEC type connector mounted on the
rear of the power supply chassis.
RELIABILITY
The power supply reliability, when calculated by MIL-HDBK-217; latest revision,
are exceed 100.000 hours with all output at maximum load and an ambient
temperature of 25℃.
2.6.2. Redundant 337W Power Supply
The redundant 337W power comes with power cage, 337W main power & 2nd 337W main
power (optional)
337W Redundant
power cage
Main power
module
337W main power
X 2 pcs
337W main power
User’s Guide
