Parts Description
2-9
2.6. Power Supplies
The H800 supports standard ATX 12V and redundant 337W (with or without 2
nd
power)
power supplies.
2.6.1 Standard ATX 12V power supply
Before Assembly standard ATX 12V power supply, it must assemble power bracket with
power than can install to chassis.
b
Power Bracket
Standard ATX 12V
350/400W
Standard
ATX
2.6.1.1. 350W ATX 12V Power Supply Specification
GENERAL REQUIREMENTS
This specification describes a 350 watts power supply.
With + 5V stand-by and remote ON/OFF control for ATX system.
User’s Guide
