APE 50 - I-2. Machine Specifications

7032 SOUTH 196th - KENT, WA 98032 - (253) 872-0141 / FAX (253) 872-8710
OPERATION / MAINTENANCE MANUAL
MODEL 50 VIBRATORY HAMMER WITH MODEL 260 POWER UNIT
1300
56 Tons (498 kN)
0 - 1800
7/8" (22mm)
100 Tons (890 kN)
56 Tons (497 kN)
100' (30 m)
6900 lbs. (3136 kg)
52" (1,320 mm)
16" (406 mm)
61" (1,549 mm)
75" (1,905 mm)
I. GENERAL INFORMATION (Continued...)
I-2.
Machine Specifications
I-2A. Model 50 Vibro - (Table 1-A.)
Eccentric Moment
Drive Force
Frequency (cpm)
Amplitude
Pile Clamp Force
Line Pull for Extraction
Hydraulic Hose Length
Suspended Weight
Length
Width
Height
Height with Clamp*
* Weight and height includes sheeting clamp and 1/2 of hose bundle.
260h.p.Cummins 6CT8.3
260 (194 kW)
2200 rpm
4,500 psi (310 bar)
80 gpm (303 lpm)
80 gpm (303 lpm)
4,500 psi (310 bar)
6.5 gpm (25 lpm)
11,000 lbs (4,990 kg)
102" (260 cm)
50" (127 cm)
60" (152 cm)
Engine
Maximum Power
Operating Speed
Maximum Drive Pressure
Max.Hyd.Flow-Forward
Max.Hyd.Flow-Reverse
Clamp Pressure
Clamp Pump Flow @ 2100 rpm
Weight
Length
Width
Height
I-2B. Model 260 Power Unit - (Table 1-B.)
Page 1-2
1300
56 Tons (498 kN)
0 - 1800
7/8" (22mm)
100 Tons (890 kN)
20 tons
4300 lbs.
52" (1,320 mm)
14 inches (355 mm)
61" (1,549 mm)
75" (1,905 mm)
Eccentric Moment
Drive Force
Frequency (cpm)
Amplitude
Pile Clamp Force
Line Pull for Extraction
Suspended Weight
Length
Width
Height
Height with Clamp*
* Weight and height includes sheeting clamp and 1/2 of hose bundle.
