OPERATION / MAINTENANCE MANUAL
MODEL 50 VIBRATORY HAMMER WITH MODEL 260 POWER UNIT
II. MAJOR COMPONENT DEFINITION (Continued...)
II-6. Caisson Clamp Identification.
The following is a general listing of the parts for the APE Caisson Clamp and Beams. (Please see
Figure 2-F. for component location.)
1 1 Caisson Clamp Body #250101
2 6 Grease Zert #221001
3 1 Caisson Clamp Plunger/Jaw #250301
4 1 Caisson Clamp Fixed Jaw #250202
5 2 Bolt - SHCS 5/8" x 4" #124214
6 2 Lock Washer 5/8" High Collar #124115
7 2 Male Wedge Half #243102
8 2 Female Wedge Half #243105
9 2 Wedge Bolt w/Washer #124211
10 2 Wedge Nut w/Washer #124212
11 17 Bolt - SHCS 1 1/2" x 3 1/2" #124201
12 17 Lock Wa. - 1 1/2" High Collar #124202
13 1 Clamp Cylinder #250001
14 2 #6 SAE/#6 JIC 45 Deg. Fitting #222002
15 8 Bolt - SHCS 1 1/4"NFx3 1/2"GR.8 #124204
16 8 Lock Wa. - 1 1/4"High Collar #124205
17 1 Cylinder End Cap #250302
QtyItem Part #
Description
18 1 Cylinder Piston #250303
19 1 Plunger #250301
20 1 Bolt -SHCS 1 1/2-8 x 3" #250304
21 1 Wiper - #959-41 #
22 1 Caisson Beam 11ft. #903000
23 1 Poly Seal - #2500-4500-375B #
24 12 Bolt - SHCS 5/8-18 x 1" #
25 8 Spring Pin #250103
26 4 Wedge Spring #250104
27 1 Wear Ring - #W2-4750-750 #
28 1 Hydraulic Wedge Activator Kit #243100
29 1 Parker O-Ring #8-367 #
30 1 Parker O-Ring #2-367 #
31 1 Piston O-Ring #2-338 #
32 1 Piston Wear Ring #W2-8000-750 #
33 1 TFER8000 Bronze w/Loader Ring #
34 1 Square Ring - #4426 #
QtyItem Part #
Description
Table 2-F. Caisson Clamp Identification
Page 2-7
