7032 SOUTH 196th - KENT, WA 98032 - (253) 872-0141 / FAX (253) 872-8710
OPERATION / MAINTENANCE MANUAL
MODEL 50 VIBRATORY HAMMER WITH MODEL 260 POWER UNIT
1 4 Model 50 Eccentric Bearing #111001
2 2 Eccentric Shaft #111003
3 4 Eccentric Bearing Cover #111004
4 4 Eccentric Shaft Spacer #111002
5 2 Eccentric Weight #111007
6 1 Vibratory Motor #112001
7 2 Motor Bearing #122002
8 1 Fitting#F40X-S-8-12MJICxMBSPP #112003
9 1 Motor Bearing Cover #112005
10 1 Drive Gear #112006
11 1 Bearing Spacer #122008
12 1 Gear Spacer #122009
13 1 Gear Carrier #122010
14 1 #10 SAE Breather Plug #122014
15 1 Breather Valve #112015
16 1 Motor Guard #112013
17 1 Motor Cover O-Ring Parker#2-258 #112019
18 2 Motor O-Ring Parker #2-163 #112020
19 1 Vibratory Gearbox #113001
20 1 Bearing Spacer, narrowed #122011
21 1 O-Ring .070 C/S BUNA 70 Cord #113003
22 1 Magnetic Drain Plug #123004
23 1 Sight Gauge #123005
24 1 Gearbox Oil Level Plug #123006
25 1 Oil Fill Plug #123012
26 1 Center Bracket #123015
27 1 Outer Suppressor Housing #310101
28 4 #16 PIPE x 16 JIC #411018
29 2 Code 62 Split Flange #113010
30 6 Flange O-Ring #2-225 #113020
31 1 Bearing Cover O-Ring #2-276 #113101
32 1 Bolt Kit #114000
33 1 1/8" Grease Zert #211001
34 1 Jaw Pin #211002
35 1 Movable Jaw #211005
36 1 Fixed Jaw #211011
37 1 Sheet Pile Guide Assy. #211017
38 1 Clamp Body #211019
39 1 Clamp Cylinder - Model 150 #212001
40 2 #6 SAE / #6 JIC 45Deg. Fitting #212002
41 1 Plunger #212301
42 1 Cylinder End Cap #212302
43 1 Cylinder Piston #212303
44 -- Bolt-SHCS 5/8"NF x 1" (Machined) #114209
45 1 6" Rod Wiper #959-53 #212015
46 1 Type B Polypak #25006000-3758 #212016
47 1 Back-Up Ring #8-367 N300-90 #212017
48 2 O-Ring 70 Duro #2-367 #212018
49 1 Wear Ring #W125-6250-750 #212014
50 1 Piston Ring #TFE-R-30008 Bronze #212011
51 1 Parker O-Ring #2-356 #212013
52 1 Square Ring #4426 #212012
53 1 Wear Ring #W125-8000-750 #212020
54 -- ---------- ---------
55 8 Small Elastomers #311004
56 -- ---------- ---------
57 1 Center Pin #311006
58 -- ---------- ---------
59 6 Bolt-SHCS 7/8"NC x 2" #114218
60 1 Pop-Off Valve #311009
61 1 Check Valve #311015
62 2 #12 PIPE #12 JIC Fitting #421016
63 6 #6 PIPE #6 JIC Fitting #421017
64 2 Danger Sticker - Small #000109
65 2 CAP #6 JIC #123011
66 1 Hose, Suppressor, Case Drain #411003
67 2 Hose, Suppressor, Clamp #411004
68 2 Hose, Suppressor, Motor Feed #411032
69 -- ---------- ---------
70 2 Hose, Pigtail, Motor Feed #411010
71 1 Hose, Pigtail, Case Drain #421009
72 2 Hose, Pigtail, Clamp Line #421010
73 -- ---------- ---------
74 11 Bolt-SHCS 1/2" x 1 1/2" w/LW/FW #114307
75 -- Bolt-SHCS 3/4"NC x 6" #114104
76 -- Bolt-SHCS 3/4"NC x 1 3/4" #124101
77 -- Bolt M14 x 30 #124112
78 -- Bolt-SHCS 3/4"NC x 1 3/4" #124101
79 -- Bolt-SHCS 5/8"NC x 2" #114114
80 -- Lockwasher 5/8" High Collar #114115
81 -- Bolt-SHCS 1/2"NC x 1" #114107
82 -- SAE 3/4" Flatwasher #114305
83 -- Bolt-SHCS 3/4"NC x 1 3/4" #124101
84 -- Bolt-SHCS 3/4"NC x 2 1/2" #114301
85 -- Lockwasher 3/4" High Collar #114105
86 -- Bolt-SHCS 1"NC x 9" #114206
87 -- 1" Lockwasher - High Collar #114207
88 -- Bolt-SHCS 1 1/2" x 3 1/2" #114201
89 -- 1 1/2" Lockwasher - High Collar #114202
90 -- Bolt-SHCS 1"NC x 3" #114208
91 -- Bolt 1 1/4"NF x 3 1/2" GR.8 Hex #114204
92 -- 1 1/4" Lockwasher - High Collar #114205
QtyItem Part #
Description
II. COMPONENT DEFINITION (Continued...)
II-1. Component Identification
The following is a general listing of the APE 50 major components and part numbers.
(Please see Figure 2-A. for component location.)
QtyItem Part #
Description
Table 2-A. Component Identification
Page 2-2
