OPERATION / MAINTENANCE MANUAL
MODEL 50 VIBRATORY HAMMER WITH MODEL 260 POWER UNIT
7 ft. Caisson Beam (#901000)
8 ft. Caisson Beam (#902000)
11ft.Caisson Beam (#903000)
Caisson Clamp (#250000)
Figure 1-G. Optional Attachments
90 Degree Adapter
Plate (#905000)
4 ft. Extension Adapter
(#906000)
Clamp Attachment
APE 90 DEGREE
ADAPTER WITH EXTENSION
APE CAISSON CLAMP
I. GENERAL INFORMATION (Continued...)
I-3D. Optional Attachments
The following are some of the optional attachments for the APE Vibratory Hammers. (Contact APE
or your local APE distributor for more information about these and other available equipment.)
APE DELUXE CONCRETE /
WOOD CLAMP
(#907000)
Page 1-7
