OPERATION / MAINTENANCE MANUAL
MODEL 50 VIBRATORY HAMMER WITH MODEL 260 POWER UNIT
V. MAINTENANCE (Continued...)
V-7A. Power Unit - Filters, Fluid Types, and Capacities. (Table 5-A.)
FILTERS
LOCATION ENGINE FILTER TYPE QUANTITY
Engine Oil: CAT 3116 CAT 1R739 1 each
Cummins 6CTA Cummins #LF3000 1 each
Engine Fuel: CAT 3116 CAT 1R740 1 each
Cummins 6CTA Cummins #FS1212 1 each
Air Filter: CAT Engines CAT 7W5389 1 each
Cummins 6CTA Cummins #256837 1 each
Hydraulic Oil Filters: ------------- Pall 750OSDS8H 2 each
Hand Pump Filter: ------------- Fairley Arlon FA35-10 1 each
ENGINE OIL TYPES AND
CAPACITIES
LOCATION ENGINE OIL TYPE CAPACITY
Hydraulic Oil-Main: ------------- Mobil EAL 224 Veg. 300 gallons
Hyd Oil-Reserve: ------------- Mobil EAL 224 Veg. 55 gallons
Engine Oil: CAT Engines CAT 15W40 48 quarts
Cummins 6CT8.3 SAE 15W40 40 quarts
Engine Water: ------------- 27 gallons
Fan Drive: -------------
Governor Control: -------------
GearBox: -------------
50/50 Water/Glycol
Multi-Purpose Grease
Multi-Purpose Grease
Schaffer 268
See small sight glass in center of gearbox between hydraulic motors. Oil should be filled to this level.
Change every six months.
Page 5-3
