7032 SOUTH 196th - KENT, WA 98032 - (253) 872-0141 / FAX (253) 872-8710
OPERATION / MAINTENANCE MANUAL
MODEL 50 VIBRATORY HAMMER WITH MODEL 260 POWER UNIT
VII. MODEL 260 POWER UNIT (Continued...)
VII-1C.
Return Filter.
Returning fluid is filtered by the return filter item #8.
VII-1D.
Heat Exchanger
The heat exchanger, item #9 cools the hydraulic fluid returning from the vibrator.
VII-1E. Manual Pump
A manual pump, item #14 is provided to fill the hydraulic reservoir. A hand valve, item #11, prevents
loss of fluid from the reservoir back through the manual pump.
VII-1F.
Hydraulic Oil Temperature
A temperature gauge #10, indicates hydraulic oil temperature. The sending unit is mounted on the
outboard side of the heat exchanger just behind the control panel and accessed through the swinging
front door.
1 1 Sight Gauge #G607-30-A- 1-1/2" LDI #523010
2 1 Sight Gauge #G607-06-A- 1-1/2" LDI #523011
3 1 Air Breather #BF-16 LENZ #523012
4 1 Suction Strainer, 2-1/2" #SS-250-5 Zinga #523013
5 1 Suction Strainer, 3" #SS-300-5 Zinga #523014
7 3 Pressure Gauge, 0-6KPSI #7718-0-6000-2.5"LBM-SG ENFM #523015
8 1 Return Filter #HH7502B32DSSBPL Pall #523016
9 1 Heat Exchanger #DH-626-1-1/L-82206 TT #523017
10 1 Temperature Gauge #K2555 30-250 DEG. F MARSH #523018
11 1 Ball Valve, 1" Brass #70-105 Apollo #523019
12 1 Piston Pump, 1.16 CID #F11-19-RUSH-T Volvo #523020
13 1 Gear Pump , 7.2 x 5.4 CID #P365B178BIAB2-7 (SPL) AB15-1 CSI #523021
14 1 Hand Pump #PA-414 Blackmer #523022
21 1 Drive Manifold #D-14625 PFS #523023
22 1 NG25 4/3 00 24VDC DIN #0-810-010-722 Bosch #523024
23 1 NG25 Back-Pressure Valve #1-817-419-038 Bosch #523025
24 2 NG6 Pilot Restrictor #1-810-120-009 Bosch #523026
25 1 NG25 Relief Valve #0-811-102-170 Bosch #523027
26 1 3-Way Thermostatic Valve #2B0CT12001 AMOT #523028
27 1 D03 Shuttle Valve Module #CSAA-EXN-GBS Sun #523029
28 1 Check Valve, 1/4" NPT #2349B-2MP Circle Seal #523030
29 1 Tapping Plate, P #AD03-TP-PT-4P Daman #523031
30 1 Snubber #NSAB-KXV-BA Sun #523032
31 1 Clamp Manifold #D-14605 PFS #523002
32 1 NG10 Relief Valve #0-811-101-170 Bosch #523033
33 1 NG10 4/3 00 24VDC DIN #0-810-001-708 Bosch #523034
34 1 NG10 P.O.Check Mod. , A #0-811-020-016 Bosch #523035
35 1 Check Valve Cartridge #CXDA-XCN Sun #523036
36 1 Pressure Switch, 8 KPSI #OE4-SBHS-8K Oildyne #523037
37 2 Disconnects #6-S30-3 Safeway #523038
38 2 Disconnect Male/Female #400100 APE #523039
39 1 Disconnects #5100-S5-12B Aeroquip #520040
41 1 P365 Unloader Manifold #D-15034 PFS #523041
42 1 Check Valve Cartidge #ICT-B16-N03 Inserta #523042
43 1 #20 2/2 N.O. Solenoid Vlv. #SV3-20-O-0-00 Modular Control #523043
44 1 24VDC DIN Coil #30580 Modular Control #523044
VII-1G. Hydraulic Components - Table 7-A.
ITEM QTY DESCRIPTION PART NUMBER MFG. APE, P/N
Page 7-2
