Detailed descriptions of all the available test parameters in Step Mode are indexed in the following
table:
Step Mode - Test Parameters
Parameter Setting/Range Description
Count 0 – 50000 0=Off Sets the number of counts.
Trigger Auto/Manual Sets the trigger to auto or manual for triggering the counts.
Base Time/Cycle Sets the base to time or cycle.
Range
Auto
Sets the power source in an Auto Range mode. The power source will
automatically interpret the voltage range and switch to high or low
voltage output range.
High
Sets the power source in the High Range mode for voltage output.
The current will be limited to half of its full range. See section 3.1
Specifications.
Low
Sets the power source in the Low Range mode for voltage output. Full
current will be available in this mode. See section 3.1 Specifications.
Wave
SINE, TRIANGLE,
SQUARE, CSIN
Sets the output waveform to the desired type. See section 4.4.2 for a
graphical representation of each wave type.
Start Angle 0 - 359°
Provides flexibility to select the starting angle of the sine wave when the
output voltage is generated.
Vac 0.0 – 310.0V Starting AC voltage for the sequence.
F 5 – 1200Hz Starting frequency for the sequence.
Vdc 0.0 – 420.0V Starting DC voltage for the sequence.
dV 0.0 – 310.0V Sets the step-up or step-down AC voltage.
dF 5 – 1200Hz Sets the step-up or step-down frequency.
dDC 0.0 – 420.0V Sets the step-up or step-down DC voltage.
Time Unit ms, s, m, h Sets the unit of time for the counts.
Time 1.0 – 999.9s Sets time for the counts.
