List Mode - Sequence Parameters
Parameter Setting/Range Description
Wave
SINE, TRIANGLE,
SQUARE, CSIN
Sets the output waveform to the desired type.
Start Angle 0 - 359°
Provides flexibility to select the starting angle of the sine wave when the
output voltage is generated.
Vs 0.0 – 310.0V Start AC voltage for the sequence.
Fs 5 – 1200Hz Start frequency for the sequence.
DCs 0.0 – 420.0V Start DC voltage for the sequence.
Ve 0.0 – 310.0V End AC voltage for the sequence.
Fe 5 – 1200Hz End frequency for the sequence.
DCe 0.0 – 420.0V End DC voltage for the sequence.
Time Unit ms, s, m, h Sets the units of time for a sequence.
Time 1.0 – 999.9s Sets time for the sequence.
A-Hi Delay 0.0 – 999.9s
Provides flexibility to program a time delay to allow the A-Hi limit to be
exceeded (for an amount of time) without resulting in the test to fail.
Detailed descriptions of all the available test parameters in the List Mode are listed in the following table:
SEQ 1 SEQ 2 SEQ 3
Wave Sine Wave Sine Wave Sine
Start Angle 90 Start Angle 0 Start Angle 0
Vs 20 Vs 20 Vs 20
Fs 50 Fs 50 Fs 50
DCs 0 DCs 0 DCs 0
Ve 80 Ve 20 Ve 100
Fe 50 Fe 50 Fe 400
DCe 0 DCe 100 DCe 0
Time unit ms Time unit ms Time unit ms
Time 75 Time 80 Time 100
The previous waveform was generated using the following parameters of the List Mode sequences:
