List Mode - Additional Metering
Parameter Setting/Range Description
A-Hi
See Specifications
in section 3.1
Provides the flexibility to program a maximum current threshold or ceiling
level. When this level is reached a failure will occur.
A-Lo
See Specifications
in section 3.1
Provides the flexibility to program a minimum current threshold or floor
level. If a minimum current level is not reached a failure will occur. This
ensures a load is attached to the power source and there is a minimum
current present.
P-Hi
See Specifications
in section 3.1
Provides flexibility to program a maximum wattage threshold or ceiling
level. When this level is reached a failure will occur.
P-Lo
See Specifications
in section 3.1
Provides flexibility to program a minimum wattage threshold or floor level.
If a minimum wattage level is not reached a failure will occur. This ensures
a load is attached to the power source and there is a minimum wattage
present.
PF-Hi 0.000-1.000
Provides flexibility to program a maximum power factor threshold or
ceiling level. When this level is reached a failure will occur.
PF-Lo 0.000-1.000
Provides flexibility to program a minimum power factor threshold or floor
level. If a minimum power factor level is not reached a failure will occur.
This ensures a load is attached to the power source and there is a minimum
power factor present.
AP-Hi
See Specifications
in section 3.1
Provides flexibility to program a maximum peak current threshold or
ceiling level. When this level is reached a failure will occur.
AP-Lo
See Specifications
in section 3.1
Provides flexibility to program a minimum peak current threshold or floor
level. If a minimum peak current level is not reached a failure will occur.
This ensures a load is attached to the power source and there is a minimum
peak current present.
Q-Hi
See Specifications
in section 3.1
Provides flexibility to program a maximum reactive power (VAR) threshold
or ceiling level. When this level is reached a failure will occur.
Q-Lo
See Specifications
in section 3.1
Provides flexibility to program a minimum reactive power (VAR) threshold
or floor level. If a minimum VAR level is not reached a failure will occur.
This ensures a load is attached to the power source and there is a minimum
VAR present.
CF-Hi 0.00 – 10.00
Provides flexibility to program a maximum crest factor threshold or ceiling
level. When this level is reached a failure will occur.
CF-Lo 0.00 – 10.00
Provides flexibility to program a minimum crest factor threshold or floor
level. If a minimum crest factor level is not reached a failure will occur.
This ensures a load is attached to the power source and there is a minimum
crest factor present.
VA-Hi
See Specifications
in section 3.1
Provides flexibility to program a maximum apparent power (VA) threshold
or ceiling level. When this level is reached a failure will occur.
VA-Lo
See Specifications
in section 3.1
Provides flexibility to program a minimum apparent power (VA) threshold
or floor level. If a minimum VA level is not reached a failure will occur.
This ensures a load is attached to the power source and there is a minimum
VA present.
