List Mode - Program Setup
List Mode Program Setup parameters only apply when Trigger is set to Manual. These parameters determine what happens before you
trigger the first sequence of the List Mode output. If the Trigger is set to Auto and you start the test these parameters will not matter since
the first sequence starts right away.
Parameter Setting/Range Description
Count 0 – 50000, 0=Off Sets the number of counts.
Trigger Auto/Manual Sets the trigger to auto or manual for triggering the counts.
Base Time/Cycle Sets the base to time or cycle.
Auto
Sets the power source in an Auto Range mode. The power source will
automatically interpret the voltage range and switch to high or low
voltage output range.
High
Sets the power source in the High Range mode for voltage output.
The current will be limited to half of its full range. See section 3.1
Specifications.
Low
Sets the power source in the Low Range mode for voltage output. Full
current will be available in this mode. See section 3.1 Specifications.
Vac 0.0 – 310.0V
Starting AC voltage for the test when Trigger is set to Manual. This will be
the AC voltage output until you trigger the sequence manually.
F 5.0 – 1200Hz
Starting frequency for the test when Trigger is set to Manual. This will be
the frequency of the output until the you trigger the sequence manually.
Vdc 0.0 – 420.0V
Starting DC voltage for the test when Trigger is set to Manual. This will be
the DC voltage output until you trigger the sequence manually.
Angle CONT OFF/ON
Phase angle of the AC output. If set to OFF, each SEQ with an AC wave
simply starts its phase at whatever its Start Angle is set to. If Angle CONT
is set to ON, the SEQ Start Angles are ignored, the phase attempts to be
“continuous”, and the next SEQ phase angle is set to whatever the last
SEQ ended at.
