Code Description
Process to Clear
Press EXIT key Wait 5sec,
Press EXIT key
Reboot. If error
message repeats
contact manufacturer
Contact
Manufacturer
SET_FAIL
Displayed when the voltage
value for AC+DC coupling
is greater than the voltage
range:
Hi – 438V, Lo – 219V
•
RCP-PEAK
Displayed when the power
source detects negative
current feeding back into
the source. RCP_PEAK will
display when the negative
peak power exceeds the
following values:
Model 8505 – 100W
Model 8512 – 250W
Model 8520 – 400W
Model 8540 – 800W
•
RCP
Displayed when the power
source detects negative
current feeding back into the
source. RCP will display when
the negative power exceeds
the following values:
Model 8505 – 25W
Model 8512 – 62.5WW
Model 8520 – 100W
Model 8540 – 200W
•
AC-OVP
Displayed when the input
voltage to the power source
is detected to be greater than
272V.
• •
AC-LVP
Displayed when the input
voltage to the power source
is detected to be less than
81V for models 8505, 8512 &
8520, and less than 171V for
model 8540.
• •
PFC_OVP
Displayed when the voltage is
greater than 425V for power
factor correction.
• •
PFC_LVP
Displayed when the voltage
is less than 310V for power
factor correction.
• •
IPFC_OCP_Peak
Displayed when the peak
current during the power
factor correction is as follows:
Model 8505 > 55Apeak
Model 8512 > 66Apeak
Model 8520 > 90Apeak
• •
