AQ M-Tech AB Ultrasound Controller Manual 43
the menu system of DP72. Calibration takes about 1-5 seconds and during this time DP72 will not
accept any new calibration commands (calibration in progress is shown in response data 1 bit7).
Response Data
Most of the Response data is the same data as shown in SHOW DATA menu and the start
screen. The format is 8 bit unsigned and in some cases 16 bit unsigned. Chapter SHOW DATA
gives more information about the data.
Air Sensor: Response data 1 and 2 bit 0 shows the Filtered Air/Liquid-data for the selected
sensitivity. Filtered Air/Liquid-data for all sensitivities are available in Response data 3 and 4 and
can be used to show different bubble sizes or change sensitivity without changing any settings.
The indication of Air is always minimum 0,5s even if a bubble passes quickly through the Air
Sensor.
Level Sensor: For Measured Level %, the value 255 corresponds to 100%. For Measured Level mm
the format is 16 bit unsigned data: high byte and low byte
Request Data table
TROUBLESHOOTING
The Profibus status-symbol on the start screen at the bottom right corner of the display gives
information for troubleshooting.
When Profibus is working correctly, Profibus status-symbol should show alternating > <
indicating data communication.
If the Profibus status-symbol shows it means DP72 do not detect any communication. The
reason can be Profibus-cable is not connected or Profibus Master is inactive.
If the Profibus status-symbol shows it means DP72 detects communication but it is not correct
Profibus telegrams. Bitrate or cable polarity could be wrong.
If the Profibus status-symbol shows T it means DP72 detects correct Profibus-telegram but
nothing is addressed to DP72. The reason can be wrong address or wrong master settings.
If the Profibus status-symbol shows P it means the Profibus master is sending parameter
telegrams. If P is shown repeatedly it means Profibus master is repeatedly sending parameter
telegrams but DP72 do not accept them. Something is wrong with the parameter telegrams. The
reason can be the master in configured with wrong gsd-file or old gsd-file version.
If no Profibus status-symbol is shown at all it means Profibus is not enabled.
Request
Data
Air Sensor Mode
Level Switch Mode
Level Sensor Mode
Gel Sensor Mode
1
bit0: 0= Air 1=Liquid
bit1: 1= calibr AS1
bit2: 1= calibr AS2
bit3: 0
bit4: 0
bit5: 0
bit6: 0
bit7: 0
bit0: 0= Air 1=Liquid
bit1: 1= calibr LS1
bit2: 1= calibr LS2
bit3: 1= calibr LS3
bit4: 1= calibr LS4
bit5: 0
bit6: 0
bit7: 0
bit0: 0= Air 1= Liquid
bit1: 1= calibr Level1
bit2: 1= calibr Level2
bit3: 0
bit4: 0
bit5: 0
bit6: 0
bit7: 0
bit0: 0
bit1: 1= calibr Liquid GS1
bit2: 1= calibr Liquid GS2
bit3: 1= calibr Liquid GS3
bit4: 1= calibr Liquid GS4
bit5: 0
bit6: 0
bit7: 0
