13. Parameter settings
Air Sensor Mode
TYPE
DIAMETER
FILTER
No Air Sensor
No Air Sensor
integrate 1ms
SAC or CCS
2 mm
integrate 3ms
SAC Ex or CCS Ex
3 mm
integrate 10ms
FCS
4 mm
integrate 30ms
PAC or FCP
4,5 mm
integrate 0,1s
FCS Ex
5,7 – 6,3 mm
integrate 0,3s
DAP or APS
6,4 – 7,4 mm
integrate 1s
7,4 – 8,4 mm
integrate 3s
SENSITIVITY
8,4 – 9,5 mm
delay 0,3s
very very low
9,5 – 10,5 mm
delay 1s
very low
10,6 – 11,8 mm
delay 3s
Low
11,9 – 13,1mm
delay 10s
medium
13,2 – 14,9 mm
High
15,0 – 16,9 mm
FREQUENCY
17,0 – 18,9 mm
Auto
mA output
19,0 – 21,0 mm
2,0MHz
disabled
21,0 – 23,8 mm
2,2MHz
Normal Measurement Data
23,9 – 27,8 mm
All Sensitivities
27,9 – 32,3 mm
RELAY
32,4 – 36,5mm
Open AS1 Liq,Close AS1 Air
36,5 – 39,8 mm
Open AS1 Air,Close AS1 Liq
39,9 – 43,8 mm
Open AS2 Liq, Close AS2 Air
43,9 – 48,5 mm
Open AS2 Air,Close AS2 Liq
48,5 – 53,1 mm
53,2 – 57,6 mm
57,7 – 62 mm
62 – 67 mm
67 – 75 mm
