AQ M-Tech AB Ultrasound Controller Manual 45
Response
Data byte
Level Sensor Mode
Gel Sensor Mode
1
Level Sensor 1
bit0: velocity sensor 2:
0=Air 1=Liq
bit1: 1= no sensor 1 or 2
bit2: 1= calibration missing
bit3: 1= error
bit4: 1= no echo
bit5: 1= OVER (>100%)
bit6: -
Level Switch 1
bit0: 0=no Gel 1=Gel
bit1:
bit2:
bit3:
bit4: 1=no sensor
bit5:
bit6:
bit7: 1=calibration in progress
2
Level Sensor 3
(same as above)
Level Switch 2
(same as above)
3
Level Sensor 1
Measured Level % (255=100%)
Level Switch 3
(same as above )
4
Level Sensor 3
Measured Level %
Level Switch 4
(same as above)
5
Level Sensor 1
Measured Level mm High byte
Level Switch 1
Gelconc % (255=25,5%)
6
Level Sensor 1
Measured Level mm Low byte
Level Switch 2
Gelconc % (255=25,5%)
7
Level Sensor 3
Measured Level mm High byte
Level Switch 3
Gelconc % (255=25,5%)
8
Level Sensor 3
Measured Level mm Low byte
Level Switch 4
Gelconc % (255=25,5%)
9
Sensor 2
Sound velocity m/s High byte
Level Switch 1
Signal dB
10
Sensor 2
Sound velocity m/s Low byte
Level Switch 2
Signal dB
11
Sensor 4
Sound velocity m/s High byte
Level Switch 3
Signal dB
12
Sensor 4
Sound velocity m/s Low byte
Level Switch 4
Signal dB
13
Level Sensor 1
dBWR
Level Switch 1
Liq WR sensor dB
14
Level Sensor 3
dBWR
Level Switch 2
Liq WR sensor dB
15
Level Sensor 1
Echo strength dB
Level Switch 3
Liq WR sensor dB
16
Level Sensor 3
Echo strength dB
Level Switch 4
Liq WR sensor dB
