Generator operation
Indicates the work mode of the
generator (Internal timers, External
timer, Proportional).
Salinity level
Indicates if the level of salinity is
sufficient or insufficient.
Temperature sensor
Indicates the state of the "Temperature
sensor error" alarm.
Polarisation time left
Indicates the remaining time of
current polarisation. At the end, after
the Clean interval, the polarity of the
voltage sent to the cell will be
switched.
Flow & Pressure
Indicates whether flow is present or not.
Current
Indicates the state of the "Low current"
alarm.
Cycle time
Indicates the sum of ON and OFF
time.
Shutter
Indicates if the shutter is open or
closed.
Cell maintenance
Indicates it is necessary to check the
cell or to run the maintenance
operations.
Check cell
Indicates the time left before
checking the cell or running the
maintenance operations.
Recirculation pump relay state
Indicates if the relay of the recirculation
pump is open or closed.
Cell replacement early warning
Indicates that the generator cell will
soon need to be replaced.
Cell replacement
Indicates the time left before
replacing the generator cell
Recirculation pump state
Indicates if the recirculation pump is on
or off.
Cell replacement
Indicates that it is necessary to replace
the cell of the generator.
✓ The PROGRAMMING/SETTINGS tab programmes and sets all the functionalities of the chlorine
generator.
Pool
Chlorine/Rx (Generator work mode:
proportional)
States/phases
duration
Pool type
Indicates or sets the pool type (pool
or SPA).
Ppm max (ppm)
Indicates or sets the maximum Chlorine value
(depending on the type of chlorine probe you are
using).
Boost (hours)
Indicates or sets the
duration of the Boost state.
Pool Capacity (cu. m / gal)
Indicates or sets the dimensions of
the pool.
Set point (ppm / mV)
Indicates or sets the value of Chlorine or Redox Set
Point.
Mixing (hours)
Indicates or sets the
duration of the Mixing state.
Shutter Filter (hours)
Indicates or sets the duration of the
shutter filter, i.e. the time in which
chlorine generation must be kept
constant, although reduced.
Proportional range (ppm/mV)
Indicates or sets the value of Chlorine or Redox
proportional range.
Start-up (days)
Indicates or sets the
duration of the Start-up
state.
Electrolytic cell
Chlorine (Generator work mode: internal or
external timers)
Cycle time (minutes)
Indicates or sets the cycle
time of chlorine generation,
i.e. the sum of ON and OFF
time.
Chlorine set (%)
Indicates or sets the percentage of
Chlorine to be generated, compared
to the maximum capacity.
Corresponds to the ratio between
ON time and cycle time, in case
other compensations such as
temperature or UV are not involved.
Temperature correction
Indicates or sets the state of correction according to
the temperature to apply to the chlorine percentage to
be generated (Yes, No).
pH (probe
supported)
Generator operation
Indicates or sets the work mode of
the chlorine generator (Internal
timers, External timer, Proportional).
UV correction
Indicates or sets the type of UV correction to apply to
the chlorine percentage to be generated (Off, Cold
shady, Cold Sunny, Mild shady, Mild Sunny, Tropical
shady, Tropical sunny)
Set point
Indicates or sets the pH
Set Point value.
