Aqua SALT+ - Tabs

AQUA SALT
+
MAINTENANCE AND INSTRUCTION MANUAL
Salt chlorine genera ENGLISH
ADSP7000753 rev. 5.0 09/07/2019 40/51
8.5 TABS
✓ The USER tab controls some operating parameters of your chlorine generator
Device state
Last modification to the parameters
Alarms
Device state
Indicates the current state of the
device (Work, Boost, Mix, Start-up,
Backwash, Off).
Last modification date
Indicates the date of the last modification
to the parameters of the device.
Flow
Indicates the state of the Absent Flow
alarm.
Time left
Indicates the remaining time of the
current state, for Work, Boost, Mix or
Start-up.
Pool
Recirculation pump state
Indicates the state of the alarm
regarding the lack of power supply to the
recirculation pump
Winter / Shutter
Indicates if Winter mode is on or
shutter is closed.
Pool type
Indicates the pool type (pool or SPA).
High temperature
Indicates the state of the High
Temperature alarm.
Phase
Analogue/digital inputs
Low temperature
Indicates the state of the Low
Temperature alarm.
Phase
Indicates the current phase of the
device (Pause, Recirculation timer
Wait, Timer Wait, Flow Wait,
Flow stabilization, Work on, Work
off, Clean, backwash phases).
Chlorine/Rx (ppm/mV)
Indicates the value of Chlorine or Redox
read by the respective probe, if
supported.
Low production
Indicates the state of the Low Production
alarm.
Time left
Indicates the time left for the current
phase, for Flow stabilization, Work
on, Work off and Clean.
Chlorine/Rx Set Point (ppm/mV)
Indicates the value of Chlorine or Redox
Set Point.
Insufficient production
Indicates the state of the Insufficient
Production alarm.
Electrolytic cell
pH
Indicates the pH value read by the
probe, if supported.
Too much salt
Indicates the state of the Too Much Salt
alarm.
Chlorine set (%)
Indicates and sets the chlorine
percentage to be generated.
Corresponds to the ratio between
ON time and cycle time, in case
other compensations such as
temperature or UV are not involved.
pH set point
Indicates the pH Set Point value.
Ice
Indicates the state of the alarm "possible
icing".
Chlorine set during Winter Mode
(%)
Indicates and sets the chlorine
percentage to be generated during
Winter Mode. Corresponds to the
ratio between ON time and cycle
time, in case other compensations
such as temperature or UV are not
involved.
pH level
Indicates if the level of pH corrector is
sufficient or insufficient.
OFA Cl / Rx
Indicates the state of the "Chlorine or
Redox OFA" alarm, which goes off if
Chlorine or Redox values do not
increase as they should during the set
time.
Chlorine generated (%)
Indicates the chlorine percentage
the device actually generates,
compared to its maximum capacity.
It corresponds to the ratio between
ON time and cycle time.
Temperature (°C / °F)
Indicates the temperature read by the
probe.
pH OFA
Indicates the state of the "pH OFA"
alarm, which goes off if the pH value
does not change as it should during the
set time.
Estimated chlorine generation
(g/h)
Indicates the amount of chlorine
generated in one hour. This amount
is an estimate.
Instant salinity (g/l/ppm)
Indicates the value of instant salinity.
This value is obtained from current,
voltage and temperature values.
pH level
Indicates the state of the "Insufficient pH
level" alarm.
Voltage (V)
Indicates the voltage at the two
extremities of the generator's cell.
Average salinity (g/l/ppm)
Indicates the value of average salinity.
Salinity OFA
Indicates the state of the "Salinity OFA"
alarm, which goes off if the salinity value
does not increase as it should during the
set time.
Current (A)
Indicates the current passing
through the generator cell.
Salinity Set Point (g/l / ppm)
Indicates the Salinity Set Point value.
Salinity level
Indicates the state of the "Insufficient
salinity level" alarm.
