Arcam SA10 Custom Installation Notes

11
Balance (0x3B)
Adjust the balance control.
Example
Command/response sequence to set the balance 3dB to the left:
Command: 0x21 0x01 0x3B 0x01 0x83 0x0D
Response: 0x21 0x01 0x3B 0x00 0x01 0x83 0x0D
COMMAND:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x3B
Dl 0x01
Data 0x00 – Set the balance to the centre
0x01 – 0x0C – Set the balance to the right 1, 2, ..., 11, 12
0x81 – 0x8C – Set the balance to the left 1, 2,..., 11, 12
0xF0 – Request current balance
0xF1 – Move the balance right by 1dB
0xF2 – Move the balance left by 1dB
Et 0x0D
RESPONSE:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x3B
Ac Answer code
Dl 0x01
Data 0x00 – Balance is Centred
0x00 – 0x0C – Balance is Right 1, 2,...,11, 12
0x81 – 0x8C – Balance is Left 1, 2,...,11, 12
Et 0x0D
Incoming audio sample rate (0x44)
Request the incoming audio sample rate.
Example
Command/response sequence to request the incoming audio sample rate,
where the rate is 48kHz:
Command: 0x21 0x01 0x44 0x01 0xF0 0x0D
Response: 0x21 0x01 0x44 0x00 0x01 0x02 0x0D
COMMAND:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x44
Dl 0x01
Data 0xF0 – Request incoming audio sample rate
Et 0x0D
RESPONSE:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x44
Ac Answer code
Dl 0x01
Data Incoming audio sample rate:
0x00 – 32 kHz
0x01 – 44.1 kHz
0x02 – 48 kHz
0x03 – 88.2 kHz
0x04 – 96 kHz
0x05 – 176.4 kHz
0x06 – 192 kHz
0x07 – Unknown
0x08 – Undetected
Et 0x0D

Arcam SA10 Specifications

General

Total Harmonic Distortion	0.003%
Weight	8.4kg
Type	Integrated Amplifier
Input Impedance	47kΩ
Damping Factor	50
Power Output	50W per channel (8Ω)
Frequency Response	20Hz - 20kHz (±0.2dB)
Outputs	1 x headphone
Dimensions	433mm x 87mm x 310mm
Digital inputs	2x optical, 1x coaxial
Phono input	Yes
