Arcam SA10 Custom Installation Notes

14
COMMAND:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x55
Dl 0x01
Data 0xF0
Et 0x0D
RESPONSE:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x55
Ac Answer code
Dl 0x02
Data1 0x00 (First byte of timeout counter, value is fixed)
Data2 0x00 – 0xF0 (Second byte timeout counter)
Et 0x0D
Timeout counter (0x55)
This command requests the time left (in minutes) until unit enters auto
standby.
Example
Command/response sequence for requesting the time left until timeout:
Command: 0x21 0x01 0x55 0x01 0xF0 0x0D
Response: 0x21 0x01 0x55 0x00 0x02 0x00 0xF0 0x0D
In this example, the timeout value is 0x00B4, which translates to 180 minutes
(i.e. 3 hours). The range of the value returned is from 0x0000 - 0x00F0 (0 - 240
minutes)
COMMAND:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x56
Dl 0x01
Data 0xF0 – Request lifter temperature
Et 0x0D
RESPONSE:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x56
Ac Answer code
Dl 0x01
Data 0x?? – Temperature in deg C in hex, e.g. 75degC = 4B
Et 0x0D
Lifter temperature (0x56) (SA20 Only)
Request the temperature of the lifter.
Example
Command/response sequence for requesting the temperature of the lifter
where the result is 75degC:
Command: 0x21 0x01 0x56 0x01 0xF0 0x0D
Response: 0x21 0x01 0x56 0x00 0x01 0x4B 0x0D

Arcam SA10 Specifications

General

Total Harmonic Distortion	0.003%
Weight	8.4kg
Type	Integrated Amplifier
Input Impedance	47kΩ
Damping Factor	50
Power Output	50W per channel (8Ω)
Frequency Response	20Hz - 20kHz (±0.2dB)
Outputs	1 x headphone
Dimensions	433mm x 87mm x 310mm
Digital inputs	2x optical, 1x coaxial
Phono input	Yes
