Arcam SA10 Custom Installation Notes

16
Processor mode input (0x5B)
Enable processor mode on a certain input or disable processor mode.
Example
Enable processor mode on the CD input:
Command: 0x21 0x01 0x5B 0x01 0x06 0x0D
Response: 0x21 0x01 0x5B 0x00 0x01 0x06 0x0D
COMMAND:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x5B
Dl 0x01
Data 0x00 - Disable (Default)
0x02 - Aux
0x03 - PVR
0x04 - AV
0x05 - STB
0x06 - CD
0x07 - BD
0x08 - SAT
0xF0 - Query processor mode status
Et 0x0D
RESPONSE:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x5B
Ac Answer code
Dl 0x01
Data 0x00 - Disabled
0x01 - Phono
0x02 - Aux
0x03 - PVR
0x04 - AV
0x05 - STB
0x06 - CD
0x07 - BD
0x08 - SAT
Et 0x0D
Input detect (0x5A)
Request the status of the active input.
Example
Command/response sequence where audio input is present.
Command: 0x21 0x01 0x5A 0x01 0xF0 0x0D
Response: 0x21 0x01 0x5A 0x00 0x01 0x01 0x0D
COMMAND:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x5A
Dl 0x01
Data 0xF0 - Request input status
Et 0x0D
RESPONSE:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x5A
Ac Answer code
Dl 0x01
Data 0x00 - Input not present
0x01 - Input present
Et 0x0D

Arcam SA10 Specifications

General

Total Harmonic Distortion	0.003%
Weight	8.4kg
Type	Integrated Amplifier
Input Impedance	47kΩ
Damping Factor	50
Power Output	50W per channel (8Ω)
Frequency Response	20Hz - 20kHz (±0.2dB)
Outputs	1 x headphone
Dimensions	433mm x 87mm x 310mm
Digital inputs	2x optical, 1x coaxial
Phono input	Yes
