19
Basic Functions
These RC5 codes are present on the supplied IR remote control and provide
control over basic amplifier functions.
Advanced Functions
These RC5 codes are not present on the supplied remote control but have
been created for custom install use. In order for the amp to respond to these
codes they must be transmitted from a programmable IR remote control or
over the control link using the ‘Simulate RC5 IR Command’ (0x08).
Function RC5 code
[system-command]
RC5 code
(Data1 - Data2)
Decimal Hexadecimal
Standby 16 -12 0x10 - 0x0C
Disp 16-59 0x10 - 0x3B
Mute 16-13 0x10 - 0x0D
Increase volume (+) 16-16 0x10 - 0x10
Decrease volume (-) 16 -17 0x10 - 0x11
Balance left 16-38 0x10 - 0x26
Balance right 16-40 0x10 - 0x28
PHONO 16 -117 0x10 - 0x75
CD 16 -118 0x10 - 0x76
BD 16-98 0x10 - 0x62
SAT 16-27 0x10 - 0x1B
PVR 16-96 0x10 - 0x60
AV 16-94 0x10 - 0x5E
AUX 16-99 0x10 - 0x63
STB 16-100 0x10 - 0x64
Function RC5 Code
[system-command]
RC5 Code
(Data1 - Data2)
Decimal Hexadecimal
Power On 16 -123 0x10 - 0x7B
Power Off 16 -124 0x10 - 0x7C
Mute On 16-26 0x10 - 0x1A
Mute Off 16 -120 0x10 - 0x78
Display Off 16-31 0x10 - 0x1F
Display L1 16-34 0x10 - 0x22
Display L2 16-35 0x10 - 0x23
Back (return) 16-51 0x10 - 0x33
Home 16-43 0x10 - 0x2B
Menu (Enter system menu) 16-82 0x10 - 0x52
Navigate Up 16-86 0x10 - 0x56
Navigate Left 16-81 0x10 - 0x51
OK 16-87 0x10 - 0x57
Navigate Right 16-80 0x10 - 0x50
Navigate Down 16-85 0x10 - 0x55
These codes are recognised as infra-red signals received by the front panel and as control data using the “Simulate RC5 IR command (0x08)” on page 7.
RC5 Command Codes
