Arcam SA10 Custom Installation Notes

12
COMMAND:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x52
Dl 0x01
Data 0xF0 – Request short circuit status
Et 0x0D
RESPONSE:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x52
Ac Answer code
Dl 0x01
Data 0x00 - No short circuit detected
0x01 - One of the channels has short circuit fault
Et 0x0D
Short circuit status (0x52) (SA20 only)
Request the output short circuit status.
Example
Command/response sequence for requesting the short circuit status, where
the result is no short circuit:
Command: 0x21 0x01 0x52 0x01 0xF0 0x0D
Response: 0x21 0x01 0x52 0x00 0x01 0x00 0x0D
COMMAND:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x51
Dl 0x01
Data 0xF0 – Request DC offset status
Et 0x0D
RESPONSE:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x51
Ac Answer code
Dl 0x01
Data 0x00 - OK
0x01 - DC offset detected
Et 0x0D
DC offset (0x51)
Request the output DC offset status.
Example
Command/response sequence for requesting the DC offset status where the
result is no DC offset:
Command: 0x21 0x01 0x51 0x01 0xF0 0x0D
Response: 0x21 0x01 0x51 0x00 0x01 0x00 0x0D

Arcam SA10 Specifications

General

Total Harmonic Distortion	0.003%
Weight	8.4kg
Type	Integrated Amplifier
Input Impedance	47kΩ
Damping Factor	50
Power Output	50W per channel (8Ω)
Frequency Response	20Hz - 20kHz (±0.2dB)
Outputs	1 x headphone
Dimensions	433mm x 87mm x 310mm
Digital inputs	2x optical, 1x coaxial
Phono input	Yes
