P341/EN O/B11 Operation Guide
CHAPTER 3 Commissioning and
Page 44/80 Maintenance
MiCOM P341
0600 CB CONDITION
0601 CB Operations
0602
Total ΙA Broken
0603
Total ΙB Broken
0604
Total ΙC Broken
0605 CB Operate Time
0700 CB CONTROL
0701 CB Control by
Disabled/Local/Remote/Local+Remote/
Opto/Opto+Local/Opto+Remote/Opto+
Rem+Local*
0702 Close Pulse Time
0703 Trip Pulse Time
0705 Man Close Delay
0706 Healthy Window
0709 Reset Lockout by User Interface/CB Close*
070A Man Close Rst Dly
0711 CB Status Input None/52A/52B/Both 52A and 52B*
0800 DATE AND TIME
0804 IRIG-B Sync Disabled/Enabled*
0805 IRIG-B Status Inactive/Active*
0806 Battery Status Dead/Healthy*
0900 CONFIGURATION
0902 Setting Group Select via Menu/Select via Optos*
0903 Active Settings Group 1/Group 2/Group 3/Group 4*
0907 Setting Group 1 Disabled/Enabled*
0908 Setting Group 2 Disabled/Enabled*
0909 Setting Group 3 Disabled/Enabled*
090A Setting Group 4 Disabled/Enabled*
090C Power Disabled/Enabled*
0910 Overcurrent Disabled/Enabled*
0913 Earth Fault Disabled/Enabled*
0915 SEF/REF/S Power Disabled/SEF/REF/Sensitive Power*
0916 Residual O/V NVD Disabled/Enabled*
0919
df/dt
Disabled/Enabled*
