Argo AG4HP061PH - Motor and Condenser Removal

Air-to-water Heat Pump
57
Note: firstly please cut off the power supply and discharge refrigerant out of the unit.
Operation Procedure
Illustration
AG4HP081PH; AG4HP101PH; AG4HP121PH; AG4HP141PH; AG4HP161PH; AG4HP103PH; AG4HP123PH;
AG4HP143PH; AG4HP163PH
Remove the top panel, front panel and right panel.
Fig. 1
Fig. 2
Remove the fixing nuts and then the rear panel,
connection panel and upright frame.
Remove the fixing nuts and then the front grille.
Fig. 3
Fig. 4
