Appendix B:
62
Command Description
ZS
FK"KBDFORM"
FS"KBDFORM"
V00,15,N,"Product Name ?"
C0,10,N,+1,"Product No. ?"
Q50,24
q816
S2
D8
ZT
A550,20,0,4,1,1,R,"ABC COMPANY"
B550,60,0,2,2,4,40,B,C0
A540,150,0,3,1,1,N,V00
FE
ZN
Enable the store to flash
Delete the previous one
Start of form
Variable and display message
Counter and display message
Label dimension
Label width
Speed
Darkness
Print from top
Fixed data
Barcode I25 for counter
Print the input product
End of form
Disable the store to flash
STAND-ALONE OPERATION FOR
KEYBOARD AND BARCODE READER
Apart from related hardware devices and PPLZ emulation, in order to
use keyboards and barcode readers (scanner) you should follow the
procedure as described below.
Keyboard
- Turn off the printer.
- Make a form for keyboard.
- Connect the keyboard to the keyboard I/F.
- Turn on the printer.
- Download it to the printer and save the form to the flash memory
permanently.
- Type the input data according to the instructions shown at the first
row.
2. Send the file, KBD.FRM to printer under MS-DOS
Pay attention to some major control functions
>COPY/B KBD.FRM LPT1:
Key Function
Esc Enter or exit from keyboard mode
Backspace Delete the last typed character.
F1 Next form if more than one forms exist.
Enter - Select the form.
- End of typed data.
READY (203,PPLB)
<ESC> FOR KEYBD
3. Turn off the printer, connect the
keyboard and then turn on. The
message will be displayed on
the LCD.
4. Press <ESC> to enter the keyboard
mode, the form name
Example:
press <ENTER> key to select will be show
for the selection, the form.
n
KBDFORM
↵
1. Make a command file for a form, KBD.FRM.
61
