Chapter 3: Configuration and commissioning
56 2X Series Installation Manual
Configures the types of commands sent to the fire network in
control panels with the corresponding global controls configured.
Configures a Class B network. When this option is configured, no
fault is reported for an open network.
Firenet map
The Firenet map defines the control panels included in the fire network. If a
control panel previously configured to be in the fire network is not detected, a
fault message indicating the offline status (with the Firenet ID) is reported.
To change the Firenet map settings:
1. Select Panel setup from the Main menu.
2. Select Firenet.
3. Select Firenet map.
A list of detected control panels appears on the LCD.
4. Select the control panel from the list, and then select YES (to add the control
panel to the network) or NO (to remove the control panel from the network).
5. Press F4 (Enter), and then press F1 (Back).
6. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit).
Remember to apply saved settings from the Main menu.
Firenet opmode
Available network operation modes are shown below.
Table 23: Firenet operation modes
-alone Configures a stand-alone control panel. This is the default setting for fire
alarm control panels.
Configures a networked control panel. See description below.
Configures a networked repeater. This is the default setting for repeater
panels. See description below.
In networked mode, the control panel uses the network to process and show the
alarm and fault events received from any remote panel which belong to any of
the local zones in the system.
In repeater mode, in addition to having the network panel functionality described
above, the panel indicates all events for all panels selected to be repeated or as
defined by the event filter configuration. For example, if the control panel event
filter has condition and fault reporting disabled, the repeater repeats only alarm,
prealarm, alert, and technical alarm conditions.
