Aritech 2X Series User Manual

Chapter 3: Configuration and commissioning
2X Series Installation Manual 77
Test/disable timeout
Configures a timeout value (in minutes) for zone
test and disablement operations for the local control
panel. See “Zone test/disable timeout” on page 78
for more information. [1]
060/000 [2]
[1]
This feature is not compliant with EN 54-2.
[2] Default 060/000 corresponds to 60 minutes test timeout and no disable timeout.
To change the configuration:
1. Select Field setup from the Main menu, and then Zone configuration.
2. Select General config.
3. Make the required configuration changes.
4. Press F4 (Enter), and then press F1 (Back).
5. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit).
Remember to apply saved settings from the Main menu.
Initial zone
The initial zone defines the starting point of the fire alarm control panel zone
range. The remaining zones for the corresponding control panel follow
sequentially, as shown in the table below.
Table 39: Initial zones
Control panel
Initial zone Remaining zones
One
-loop control panel 1 2 to 64
One
-loop control panel 200 201 to 263
Two
-loop control panel 1 2 to 128
Two
-loop control panel 520 521 to 647
For repeater panels without a zone board, the initial zone value is not used as
the panel has no zones. The repeater panel displays zone events of the panels
being repeated.
First zone indicator LED
The first zone indicator LED defines the zone number for the first LED (top left)
for an installed zone indicator board. The remaining zones for the corresponding
control panel follow sequentially, as shown in Table 40 below.
The initial zone range is as follows:
• Between 01 and 9960 for a 40-zone indicator board
• Between 01 and 9980 for a 20-zone indicator board
• Between 01 and 9976 for a 24-zone indicator board

Aritech 2X Series Specifications

General

Certifications	EN54-2, EN54-4
Power Supply	230V AC, 50Hz
Battery Capacity	7Ah
Current Consumption	Standby: 50mA
Humidity Range	Up to 95% RH, non-condensing
