Aritech 2X Series User Manual

Chapter 3: Configuration and commissioning
78 2X Series Installation Manual
Table 40: Zone LED indicator initial zones
Zone indicator board
Initial zone Remaining zones
20
-zone indicator board [1] 1 2 to 20
40
-zone indicator board [1] 200 201 to 239
24
-zone indicator board [2] 9976 9977 to 9999
[1]
For large cabinet control panels.
[2] For small cabinet control panels.
Note: Ensure that the zone numbers selected are inside the zone range of the
control panel in networked mode or that the zone numbers are inside the range
of the zones repeated by the control panel.
Zone test/disable timeout
The Zone test/disable timeout sets an independent timeout value (in minutes) for
zone test and disablement operations for the local control panel.
When the control panel is in a Maintenance or Installer user level, active zone
test or disablement operations stop when the corresponding timeout value is
reached.
The default test timeout value is 60 minutes. This value must be set to 000 to
disable the timeout and to force the manual cessation of zone test operations. By
default, no disable timeout value is configured.
Zones previously disabled via the Zone configuration menu are not included in
the timeout command and no changes are made to zone status.
Note: This feature is not compliant with EN 54-2.
Zone configuration
Select the Zone configuration option to configure additional zone settings, such
as the zone type (normal or confirmed with corresponding parameters), area, CIT
and ACT delays, disabled or enabled, and operation mode. Default settings are
shown in the table below.
Table 41: Zone configuration options
Option
Description Default value
Type
Configures the zone alarm confirmation type.
See “Zone alarm confirmation” on page 79 for more
information.
NML (normal, no
confirmation required)
Area [1] [2]
Configures the area number for zone types
requiring confirmation by an area.
See “Area configuration” on page 81 for more
information.
1

Aritech 2X Series Specifications

General

Certifications	EN54-2, EN54-4
Power Supply	230V AC, 50Hz
Battery Capacity	7Ah
Current Consumption	Standby: 50mA
Humidity Range	Up to 95% RH, non-condensing
