Chapter 3: Configuration and commissioning
2X Series Installation Manual 79
Description Default value
Configures CIT and ACT delays for zones that
require confirmation.
See “Confirmation Inhibition Time (CIT) and Alert
Cancellation Time (ACT)” on page 80 for more
information.
CIT: 60 seconds
ACT: 5 minutes
Enables or disables the zone (with options for
day/night mode disablement).
ENB (enabled)
Configures the zone operating mode (Mixed,
Manual, Auto, MSP, or MHA).
See “Zone operating modes” on page 81 for more
information.
Mixed
[3] Configures MCP double detection for the zone. If
checked, when two automatic devices indicate an
alarm in the zone, the second alarm is processed
as a manual call point alarm.
Disabled
Not required for zone type NML (normal, no confirmation required).
Not required for zones that confirm an alarm in the same zone.
[3] Only available for zone type NML.
To change the zone configuration settings:
1. Select Field setup from the Main menu, and then Zone configuration.
2. Select Zone configuration, and then select the corresponding zone from the
list of zones displayed.
3. Make the required configuration changes.
4. Press F4 (Enter), and then press F1 (Back).
5. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit).
Remember to apply saved settings from the Main menu.
Note: If all the devices assigned to a zone are disabled, then the zone is
considered to be disabled and is indicated accordingly on the control panel.
Zone alarm confirmation
Zone confirmation is an alarm coincidence configuration method designed to
reduce nuisance alarms. A first alarm event places the zone and the control
panel into alert status. Full alarm status is not confirmed until a second alarm is
reported in the same zone or in a configured area. See “Area configuration” on
page 81 for more information on areas.
