001-31249-EN rev. 3
Operating the Maxi Sky 2 Plus in Dual Mode30
How to Use the Gate
The Gate is a KWIKtrak accessory that allows an X-Y system to connect to another xed track section.
Fig. 58
Fig. 59
Exiting the X-Y System
1) Move the Maxi Sky 2 Plus along the mobile
tracks toward the end on which the KWIKtrak Gate
is installed.
The ceiling lift will automatically be in contact with
the gate's activation stations.
2) Move the mobile tracks over to align them with
the adjacent fixed tracks.
This action will be detected by the gate, which will
lock the two pairs of tracks together and allow the
ceiling lift to pass through.
