Technical Specications
Overall Dimensions
450 mm (17 3/4")
735 mm (28 7/8")
MIN. (509 mm 20 3/8")*
* When using a scale, add 156 mm to this dimension.
MAX. 2809 mm (110 1/2")
722 mm (28 1/2")
H
MAX. 765 mm (30 1/8”)
350 mm (13 3/4”)
350 mm (13 3/4”)
MIN. 450 mm (17 3/4”)
Fig. 82
