5.1!
Functions
You can assign controls or functions to matching knobs, buttons, joysticks
or other external controllers.
The control assigned to each parameter is displayed on the Home Screen.!
Functions can be assignment to controls on the unit in the controls page in !
the Main Menu.!
K1 - K6 !
The display will indicate that a Knob is in use !
and the function it has been assigned to control.
By example the Ramp Start is controlled by !
Knob K3 which is located here. !
!
!
B1 - B6 !
The display will indicate that a Button is in use and the
function it has been assigned to control.
By example B3 will move the head back to its pre
defined default position.The button B3 is located here.!
!
Joystick !
Indicates that the built in Joystick (1)
is assigned for use with Tilt and Pan.!
!
!
TS!
Indicates that the function is assigned to the touchscreen.!
!
Assigning Controls
Select one of the available controllers and confirm
by touching Assign.
J1H = Joystick 1 horizontal / Pan axis
Unassigning Controls
To unassign a selected controller, touch Unassign.
NOTE:
After a function was unassigned, the function
will be only available through the touchscreen.
!
Submenu!
Selecting any menu field with three points, !
will open a submenu for that function."
To Next Page
